Diamond Thin Multi-Wire Saw Machine for 0.5mm Ultra-Thin Slab Slicing
DS-U-G1212
DINOSAW
The Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine is the Single Technical Champion officially awarded in Shuitou (the World Stone Capital) and the lead drafter of the T/CMES 41001-2025 industry standard.Proven across hundreds of stone varieties with vastly different mineral structures, the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine delivers expert-level precision for both soft materials like Italian Carrara White (Mohs 3-4) and ultra-hard luxury stones like Amazonite Green.By supporting high-tensile wires of 0.35mm, 0.5mm, and 0.55mm, the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine achieves a razor-thin 0.5mm kerf, delivering a 30%+ yield increase over traditional gang saws.While global competitors lack the process intelligence to balance varied stone densities, the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine enables simultaneous production of 3mm, 5mm, and custom-thickness slabs in a single pass.
[ Click to Expand: The Elite Profit Engineering of Dinosaw Multi-Wire Saw ]
I. Profit Engineering: 0.5mm Kerf and 30% Higher Yield
- Ultra-Thin Wire Mastery: The Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine is optimized for ultra-thin diamond wires, slashing material waste to an industrial minimum of 0.5mm to ensure maximum slab count per block.
- Simultaneous Multi-Thickness Cutting: In a single production cycle, the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine can produce slabs of different thicknesses, a unique flexibility that ensures the highest profit margin for premium blocks.
II. Hardcore Hardware: HT250 Casting and 450mm Carbon Fiber Rollers
- HT250 Structural Integrity: Built with a premium HT250 cast-iron monoblock frame, the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine provides the extreme vibration damping required to maintain a 10-year precision lifespan.
- Industry-First 450mm Carbon Fiber Rollers: The Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine features unique 450mm carbon fiber rollers to minimize mechanical inertia and wire fatigue, ensuring stable high-speed cutting on any stone hardness.
III. Exclusive Technological Gap: The AI "WireSaw Recipe Master"
- "Global Versatility" Advantage: Unlike global competitors who struggle with varying stone densities, the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine integrates the "WireSaw Recipe Master" AI model.This model provides optimized parameters for both soft Mohs 3-4 marbles and ultra-hard granites, removing the reliance on manual experience.
- Full Servo Precision: Controlled by 8-10 independent Siemens or Inovance servos, the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine ensures micro-level tension synchronization, achieving "Zero-Edge Chipping" and extreme surface flatness.
1200 mmMaximum cutting size for 1.2 m-class blocks
30% LessFloor space than traditional slab-cutting lines
±0.3 mmMulti-wire slab accuracy from the first production cycle
Applicable Materials
Granite, marble, limestone, travertine and other hard stones
Certifications & Credentials
CE Certified · ISO 9001:2015 · Industry Standard Drafting Participant · 120+ Countries & Regions Served
Stone Block Cutting for High-End Interior Applications
Travertine ❯ Counters & Displays
Structural Integrity Mastery: Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine Handles Fragile Porous Stones with "Zero-Edge Chipping" Travertine used in premium countertops demands precise tension control to prevent micro-cracking during processing.The Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine features industry-unique 450mm carbon fiber rollers and 8-10 independent Siemens or Inovance servos to ensure micro-level synchronization.As the Single Technical Champion of Shuitou, the World Stone Capital, the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine ensures a high-quality decorative finish while reducing material waste by 30% compared to traditional gang saws.
Onyx ❯ Dividers & Claddings
Maximum Translucency & Yield: Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine Transforms Rare Onyx into High-Profit Assets Onyx is a rare resource where translucency is the core value for curtain walls.The Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine maximizes this value by delivering a 0.5mm ultra-thin kerf , allowing fabricators to extract more high-transparency slabs from a single block.Integrated with ABB and Siemens electrical components , the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine provides stable 24/7 production, ensuring that even the thinnest 3mm slabs maintain the structural integrity and vein continuity required for elite architectural projects.
Luxury Stone ❯ Museum Elements
The Global Benchmark for Extremes: Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine Processes Soft to Ultra-Hard Luxury Stones Museum-grade exhibits often feature stones with extreme mineral densities, such as the high-hardness Amazonite Green .The Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine is the lead drafter of the T/CMES 41001-2025 standard, utilizing its "WireSaw Recipe Master" AI model to provide instant optimized parameters for stones ranging from Mohs 3 to extreme hardness .With a maximum processing height of 2200mm , the Dinosaw Machinery Diamond Thin Multi-Wire Saw Machine provides the ultimate geometric stability and 10-year precision lifespan needed to handle the world’s most expensive and challenging luxury materials.
Real Cutting Performance & Key Metrics
The DS-U-G1212 brings full U-series architecture to compact factories: 1.2 m blocks, ±0.3 mm accuracy and 0.3–0.8 mm wire flexibility on a 35-ton cast-iron frame that fits where full-size saws cannot.
1200×1200×1200 mm
Max. Cutting Size
Built for 1.2 m-class block programs and compact factories moving into multi-wire production.
±0.3 mm
Cutting Accuracy
Grooved main rollers, spacer plates and servo tension hold ±0.3 mm across the full wire web.
35 m/s
Diamond Wire Speed
Up to 35 m/s wire speed with four 60 kW main motors (300 kW installed).
0.3–0.8 mm
Compatible Wire Range
One machine covers fine to standard wires; switch slab programs by re-spacing wires and spacer plates.
Applicable materials: Granite, marble, limestone, travertine and other hard stones.
Typical products: Standard and thin slabs, tiles and cut-to-size workpieces from 1.2 m-class blocks.
Wire count and slab output are configuration-dependent, not fixed machine limits. Actual cutting speed and accuracy vary with stone hardness, block dimensions, wire specification and on-site conditions.
Specs and options
The DS-U-G1212 is the compact size of the U series: 1.2 m maximum cutting dimension, 35 m/s wire speed and 300 kW installed power. Roller specifications (Φ400/Φ450), workstation layout (1+2) and electrical brands are configured to your project; larger U-series sizes are available when block dimensions grow.
Model
Units
DS-U-G1212
DS-U-G3220
DS-U-G3623
Maximum Cutting Size
mm
1200×1200×1200
3200×2300×2200
3600×2300×2200
Maximum Wire Speed
m/s
35
35
35
Main Motor Power
kW
60×4
60×4
90×4
Total Installed Power
kW
300
300
400
Lifting Stroke
mm
2000
2690
2690
Compatible Diamond Wire
mm
0.3–0.8
0.3–0.8
0.3–0.8
Rollers (dia. × length)
mm
Φ400/Φ450 ×1200
Φ350/Φ400/Φ450 ×2050
Φ350/Φ400/Φ450 ×2350
Number of Trolleys
/
1+2
1+2
1+2
Machine Weight
T
35
58
65
Main Roller / Quantity
mm×pcs
255(280)×8
255(280)×8
255(280)×8
Electrical Control System
/
Inovance / INVT
Inovance / INVT
Inovance / INVT
Diamond Wire Tension
N
0–260
0–260
0–260
Overall Dimensions (L×W×H)
mm
8330×5363×5200
9640×6170×6600
10150×6500×6600
Core Technology & Machine Structure
Six core systems in a compact 35-ton platform — the same architecture as the larger U-series machines. The numbered points on the machine diagram correspond to the systems below.
DS-U-G1212 Cutting Workflow
A cycle follows four steps: load the block on the lifting table, thread the wires per the slab program, apply stored or AI-recommended parameters, then lift and cut. Automatic stop protects the machine if a wire breaks.
01
Compact Stone-Lifting Platform
The G1212 lifts 1.2 m-class blocks into the wire web on a 2000 mm lifting stroke — stable cutting quality in a footprint of 8.3 × 5.4 m, about 30% less floor space than traditional cutting lines.
02
One-Piece Cast-Iron Frame
The 35-ton one-piece cast-iron monoblock damps vibration and protects long-term accuracy without a full factory rebuild.
03
Four Grooved Main Rollers
Four main rollers with precision grooves seat the wires, define slab thickness and prevent deviation; alternating servo rotation extends wire life.
04
Servo Tension Control
The 0–260 N servo tension system compensates wire elongation through the cut, keeping slab thickness consistent from first wire to last.
05
Thick/Thin Program Switching
Re-spacing wires and spacer plates switches between thick and thin slab programs, so one machine follows changing orders.
06
AI Recipes & Remote Support
The DINOSAW AI recipe system recommends parameters from stone type, hardness, block size and target thickness; remote diagnosis and online support are included.
Multi-Wire Saw vs. Single-Blade Block Cutting
A practical comparison for shops upgrading from single-blade cutting to multi-wire production.
Multi-Wire Saw vs. Single-Blade Block Cutting
Single-Blade Cutting
VS
DS-U-G1212 Multi-Wire
One slab face at a time
Output per cycle
✓Multiple slabs in a single pass
Wide blade kerf
Kerf & yield
✓Thin wire kerf, more slabs per block
Close operator attention
Labor
✓One operator supervising the cycle
Calibration-dependent
Accuracy
✓±0.3 mm direct
Cutting line
Footprint
✓Compact platform, about 30% less floor space
Note: configurations vary by brand and model; actual performance depends on the specific machine, material and working conditions.
The Manufacturer Behind the DS-U-G1212
DINOSAW is a manufacturer of CNC stone processing machinery, specializing in diamond wire saw machines and CNC stone cutting equipment. With more than 20 years of R&D and manufacturing experience, DINOSAW contributes to industry standards including T/CMES 41001-2025 for CNC wire saw machines, holds 100+ technical patents, and supplies equipment and technical support to customers in 120+ countries and regions. Its manufacturing and management systems are certified to ISO 9001, ISO 14001 and ISO 45001, with CE-compliant machinery for international markets.
DINOSAW R&D & ManufacturingMechanical Design · CNC Control Development · Assembly · Testing · Commissioning · Global Delivery
Industry Standard Drafting
DINOSAW contributes to industry standards for stone machinery, including T/CMES 41001-2025 for CNC wire saw machines, as well as standards covering multi-wire saws, combined wire saw machines and five-axis bridge cutting equipment. This work reflects the company’s long-term involvement in machine design, manufacturing, testing and quality control.
20+Years of Stone Machinery R&D & Manufacturing Experience
100+Technical Patents — Covering machine structures, CNC control, cutting systems and stone processing technologies
120+Countries & Regions Served — Equipment, installation and technical support worldwide
CE Compliance & ISO Management Systems
CE: Stone cutting machinery assessed against Machinery Directive 2006/42/EC and relevant EN standards. ISO: Management systems certified to ISO 9001, ISO 14001 and ISO 45001.
Installation Requirements & After-Sales Support
DINOSAW provides installation guidance, one month of training, remote diagnosis and spare-parts coordination for every machine.
Foundation per DINOSAW drawings; lifting equipment rated for blocks and the 35 T machine body.
Water50 L/min, recycling recommended
0.3 bar clean water for cooling; recycling protects the wire and saves water.
01 · Pre-Shipment & DeliveryMachine configuration, packaging and transport requirements confirmed before dispatch, with factory inspection and documents verified.
02 · Installation & CommissioningOn-site utilities and foundation check, machine positioning, commissioning and acceptance.
03 · Operator TrainingHands-on training covering routine CNC operation and daily checks of diamond wire, guide wheels, tensioning, cooling and lubrication.
04 · After-Sales SupportRemote technical assistance, maintenance support and spare parts coordination throughout the machine's service life.
Common Questions About DINOSAW Multi-Wire Saw Machines
If your blocks are 1.2 m class and your program is standard to thin slabs, yes — it delivers full U-series architecture (lifting feed, cast monoblock, servo tension, AI recipes) at 35 tons and 300 kW, and the same control ecosystem as the larger U models means your operators' training carries over when you scale up.
